Armoured Cable

Simplex Armoured Round Cable Singlemode G652D

GJSJV Simplex Armoured Round Cable use 600um & 900um tight buffer fiber, steel tube protect, reinforcingsteel-wire braiding(Kevlar/aramid yarn), flame-retardant jacket. High indentation strength, high tensilestrength, gopher protected, small diameter, flexibility and easy bend.

Products Details

Product Features

0.6mm or 0.9mm tight buffer fiber

Hight strength kevlar yarn member

Steel armored flexible tube, increase the cable's twist resistance

Small cable volume, and light weight

Parameters

Cable typeOD(mm)Nominal
Weight
(kg/km)
Tensile Strength(N)Crush Resistance
(N/100MM)
Bending Radius(mm)
short-termLong-termShort-termLong-termDynamicStatic
GJSJV-1xn1.8±0.216.04002002000100020D15D
GJSJV-1Xn2.8±0.218.54002002000100020D15D
Storage/Working temperature(℃)  -20~+60

Applications

1. Adopted to indoor distribution

2. As pigtail of communication equipment

3. Suitable for communication equipment served

4. Can be installed conveniently and perated simply

Ordering Information

Fiber Optic Cable Options

Fiber Optic Cable Options

Fiber Optic Cable Jacket & Diameter Options

Fiber Optic Cable Jacket & Diameter Options

Fiber Optic Cable Core Type Options

Fiber Optic Cable Core Type Options
